Features

  • Chassis Height: 3U
  • Dimensions: 19″ x 5.2 ” x 15.7″
  • Drive Bays: 1x 5.25″, 1x 3.5″, & 2x 3.5″ HDD
  • Power Supply: 2U Single or 2U Redundant Power Supply

3U Rackmount Case EJ-3U164-C Product Description

The 3U Rackmount Case EJ-3U164-C feature the standard EIA RS-310C 19″ chassis’ which will meet all of your computing needs while optimizing the space on your rack. This sleek and rigid 3U chassis has a unique thermal cooling design that includes a front cold air intake tunnel and three cooling fans so the system stays cool while running at optimal levels. The EJ-3U164-C can be used as a multipurpose server. In addition, the chassis supports Pentium 4, Pentium D, Dual Xeon, AMD 64, and Dual Opteron system boards.

Drive Bays1x 5.25″, 1x 3.5″, & 2x 3.5″ Hot-swappable Trays
Dimensions19″ x 5.25 ” x 15.7″
Power Supply(Rear Chassis Installation) 2U Single or 2U Redundant Power Max Depth 300mm
Cooling Units1 x 80mm + 2 x 40mm Heavy Duty Ball Bearing Fans
ConstructionHeavy Duty Cold Rolled Electroplated Steel
Motherboard SizeSupport ATX M/B (Max. 12″ x 9.6″ ATX/Micro ATX)
System BoardPentium 4, Pentium D, Dual Xeon, AMD 64, Dual Opteron
ColorBlack (Standard), Beige or Custom
Weight12.5kgs / 27.5lbs
Product ApplicationsMultipurpose Server
IndicatorsLEDs for Power, HDD Activity, & LAN
ButtonsRecessed Power On/Off & System Reset Thin Rocker Switches
