• Chassis Height: 3U
  • Dimensions: 19.0″ x 5.25″ x 25.6″
  • Dimensions: 483 x 133 x 650
  • Drive Bays: 1 x 5.25″, 1 x Slim CD-ROM,1 x Slim FDD & 10 x Hot Swappable Drive Trays
  • Power Supply: 2U Single up to 650W, 2U Redundant up to 460W or 3U Triple Redundant up to 650W

3U Rackmount Chassis EJ-3U6513-C Product Description

The 3U Rackmount Chassis EJ-3U6513-C feature the standard EIA RS-310C 19″ chassis’ which will meet all of your computing needs while optimizing the space on your rack. This sleek and rigid 3U chassis has a unique thermal cooling design that includes a front cold air intake tunnel and five cooling fans so the system stays cool while running at optimal levels. The EJ-3U6513-C can be used to host a web server, an email server, RAID server, Proxy server, print server, file server. It can also be used alongside surveillance systems and as a high-end workstation.

Drive Bays1 x 5.25″, 1 x Slim CD-ROM,1 x Slim FDD & 10 x Hot Swappable Drive Trays for (PATA, SATA, or SCSI 320), 2 x HDD Bracket above the Power Supply (Optional)
Dimensions483(W) x 133(H) x 650(D) mm (19″ x 5.2″ x 25.6″)
Power Supply(Rear Chassis Installation) 2U Single upto 650W, 2U Redundant upto 460W or 3U Triple Redundant up to 650W (Optional)
Cooling Units4 x 9cm (51 CFM ea.) 1 x 6cm (23.5 CFM ea.) Heavy Duty Ball Bearing Fans
ConstructionHeavy Duty Cold Rolled Electroplated Steel
ColorBlack, Beige
System BoardsDual Xeon, Dual Opteron, Pentium 4 Dual Pentium III based boards
MotherboardSupport ATX M/B (Max. to 12″ x 13″ EEB)
Expansion Slot7 x Full Length PCI Slots
IndicatorsLEDs for Power ON/OFF, 2 x HDD Fan Temperature & 3 x LAN Activity
Thermal CardInstalled
ButtonsPower On/Off, System Reset, Buzzer Reset
Door(s)1 x Front Door with Thumbscrew Lock
Weight19.6kgs / 43.2 lbs
Cu. ft.5.3
Carton Size59.4(W) x 30.9(H) x 81.8(D)(Cm) (23.4″ x 12.2″ x 32.2″)
Product ApplicationWeb Server, Email Server, RAID Server Proxy Server, High-End Workstation Print Server, File Server, Surveillance Systems
