Features
  • Chassis Height: 2U
  • Dimensions: 19″ x 3.5″ x 25.6″
  • Dimensions (mm): 483 x 88 x 650
  • EIA RS-310C 19″ Rackmount Standard
  • 25.6″ deep 2U chassis
  • Support 12″ x 13″ EATX and ATX/ micro ATX motherboard
  • 1 x Slim CD-ROM & 1 x Slim FDD & 8 x 3.5″ Swappable Trays

EJ-2U6510-C 2U Rackmount Chassis Product Description

The EJ-2U6510-C 2U Rackmount Chassis offers great expand-ability and cooling capacity for your server computer. It supports a 12″ x 13″ ATX and smaller form factor motherboard. The EJ-2U6510-C also features a quality fan filter and 4 x 80 cm cooling fan for optimum ventilation of the system.

StandardEIA RS-310C 19″ Rackmount Standard
ConstructionHeavy Duty Cold Rolled Electroplated Steel
ColorBlack (Standard), Beige or Custom
Drive Bays1 x Slim CD-ROM & 1 x Slim FDD & 8 x 3.5″ Swappable Trays & 2 x 2.5″ HDD & 1 x 3.5″ HDD (Optional)
Power Supply2U Single up to 600W or 2U Redundant up to 500W ATX P/S(Rear Installation) Max. Depth 300mm
Cooling Units4 x (80 mm = 42.5 CFM ea.) Fans
Expansion Slot2 or 3 x Horizontal ISA/PCI/AGP Option Slots or 7 x Low Profile PCI Slots
Connector Port (front)2 x USB Ports
ButtonsPower ON/OFF Momentary (Pushbutton), System Reset, Buzzer Reset
Thermal CardOptional
Front Door(s)Single Door With 2 Thumbscrews (Removable)
Dimensions (W x H x D)483 x 88 x 650 mm (19″ x 3.5″ x 25.6″)
Weight18.5 kgs / 40.8 lbs
Cu. ft.4.4
Carton Size58.8 x 25.5 x 82.5 (23.1″ x 10″ x 32.5″)
Humidity5% – 95% Non-condensing

1U & 2U Chassis Motherboard Standoff Installation Guide
